UVCommunity report
Transparent acrylic
Shared by @humber.giannini on Atomm
Important safety notice
Settings are starting points — always run a test cut on scrap before your final piece. Follow your manufacturer's guidance, wear eye protection, and ensure proper ventilation.
Laser Settings
Engrave · Bitmap · Flat SurfacePower
75
Speed
80
DPI
550
Passes
1
Thickness
3mm
dot time
300 µs
Utilización de acrílico transparente para construcción de una grilla que relaciona la frecuencia de 40 @ 80 KHz con el DPI de 400 @ 600, el mejor resultado que he conseguido con mi máquina se puede ver en la imagen con los siguientes parámetros: Potencia 75, Duración del Punto 300 us, 580 DPI, 80 KHz, Jarvis, 1 pasada.
Community Feedback
No votes yet — be the first to report how these settings worked.
Export
xTool machine: open it straight in xTool Studio, or download a .mxs (Studio → Materials → Import).
Sponsored
All American Print Supply
DTF and UV printers, supplies and xTool machines.
Code FOUNDRY: 5% off, machines included
Shop AAPS →Machine Context
BrandxTool
ModelF2 Ultra UV
Laser typeUV
Wattage5W
Compare against your own machine before treating these as a starting point.
Material Details
MaterialTransparent acrylic
Size3mm
Shop machine — xTool →
Code ERIK100 — $100 off $1,699+ (or ERIK80 — $80 off $999+)
Provenance
Source type
Community report
Shared by a maker in the community. Helpful for context, but not verified for every setup.
