DiodeCommunity report
SLATE
black
Shared by @afontanarosa01 on Atomm
Important safety notice
Settings are starting points — always run a test cut on scrap before your final piece. Follow your manufacturer's guidance, wear eye protection, and ensure proper ventilation.
Laser Settings
Engrave · Bitmap · Flat SurfacePower
40
Speed
80
DPI
500
Passes
1
dot time
100 µs
F2 PHOTO ENHANCED FROM CHAT GPT SETTING GRAYCALE 100up POWER 10 -40 DPI 500 invert pic grayscale sharp 5 bright 5 contrast 15
Community Feedback
No votes yet — be the first to report how these settings worked.
Export
xTool machine: open it straight in xTool Studio, or download a .mxs (Studio → Materials → Import).
Sponsored
All American Print Supply
DTF and UV printers, supplies and xTool machines.
Code FOUNDRY: 5% off, machines included
Shop AAPS →Machine Context
BrandxTool
ModelF2
Laser typeDiode
Wattage15W
Compare against your own machine before treating these as a starting point.
Material Details
MaterialSLATE
Color / Finishblack
BrandAMAZON
Shop machine — xTool →
Code ERIK100 — $100 off $1,699+ (or ERIK80 — $80 off $999+)
Provenance
Source type
Community report
Shared by a maker in the community. Helpful for context, but not verified for every setup.
