tilleul test grid
DiodeCommunity report

tilleul

Shared by @GG on Atomm

Important safety notice

Settings are starting points — always run a test cut on scrap before your final piece. Follow your manufacturer's guidance, wear eye protection, and ensure proper ventilation.

Laser Settings

Score · Vector · Flat Surface
Power
50
Speed
50
Passes
1
Thickness
3mm
defocus
3 mm
Avec le tilleul 3mm la découpe ce fais la plupart du temps en 2 passes, vitesse 10 et puissance 90. Pour la gravure contour, 50 an puissance et 50 en vitesse suffise. Pour la gravure profonde puissance 60 et vitesse 100, tout est bien gravé en profondeur sans cramer le bois

More tilleul settings

Same material on xTool M1 Ultra. Engrave stays the same regardless of thickness; cut changes with thickness.

Engrave (any thickness)
3mm · P60 S100
Cut by thickness
3mm · P90 S10
Score
3mm · P50 S50 · this one

Community Feedback

No votes yet — be the first to report how these settings worked.

Export

xTool machine: open it straight in xTool Studio, or download a .mxs (Studio → Materials → Import).

Sponsored
Shop xTool lasers and UV printers

Every xTool machine in this library, with our discount code.

Code ERIK100: $100 off $1,699+ (or ERIK80: $80 off $999+)

Shop xTool →

Machine Context

BrandxTool
ModelM1 Ultra
Laser typeDiode
Wattage20W

Compare against your own machine before treating these as a starting point.

Material Details

Materialtilleul
Size3mm
Shop machine — xTool →

Code ERIK100 — $100 off $1,699+ (or ERIK80 — $80 off $999+)

Provenance

Source type
Community report

Shared by a maker in the community. Helpful for context, but not verified for every setup.

Source

Shared by @GG in Atomm, xTool's community
