K9 Inner Carved Glass test grid
UVCommunity report

K9 Inner Carved Glass

Shared by @Emotion Designs on Atomm

Important safety notice

Settings are starting points — always run a test cut on scrap before your final piece. Follow your manufacturer's guidance, wear eye protection, and ensure proper ventilation.

Laser Settings

Engrave · Bitmap · Inner Engraving
Power
80
Speed
80
Passes
1
K9 crystal round keychain with an inner engraving. These are the settings we used to achieve the results in the picture. Make sure to use calipers to measure the thickness and diameter. If you have an issue with your engraving showing centered in the software but engraving closer to the bottom of the crystal, you may have to calibrate your Z-axis. Hope this helps!

More K9 Inner Carved Glass settings

Same material on xTool F2 Ultra UV. Engrave stays the same regardless of thickness; cut changes with thickness.

Community Feedback

No votes yet — be the first to report how these settings worked.

Export

xTool machine: open it straight in xTool Studio, or download a .mxs (Studio → Materials → Import).

Sponsored
All American Print Supply

DTF and UV printers, supplies and xTool machines.

Code FOUNDRY: 5% off, machines included

Shop AAPS →

Machine Context

BrandxTool
ModelF2 Ultra UV
Laser typeUV
Wattage5W

Compare against your own machine before treating these as a starting point.

Material Details

MaterialK9 Inner Carved Glass
SupplierxTool
Buy this material →

Code ERIK100 — $100 off $1,699+ (or ERIK80 — $80 off $999+)

Shop machine — xTool →

Code ERIK100 — $100 off $1,699+ (or ERIK80 — $80 off $999+)

Provenance

Source type
Community report

Shared by a maker in the community. Helpful for context, but not verified for every setup.

Source

Shared by @Emotion Designs in Atomm, xTool's community
