1/8"(3mm) Black Acrylic test grid

Fiber/InfraredCommunity report

1/8"(3mm) Black Acrylic

black

Shared by @Adam Kent on Atomm

Important safety notice

Settings are starting points — always run a test cut on scrap before your final piece. Follow your manufacturer's guidance, wear eye protection, and ensure proper ventilation.

Laser Settings

Engrave · Bitmap · Flat Surface

Power

40

Speed

80

DPI

392

Passes

1

Thickness

3mm

dot time

100 µs

Black Acrylic Settings to help you get the most enhanced images on 3mm Acrylic. Ensure that this is NOT on Blue Light setting for your XTool F1 Ultra for best results.

More 1/8"(3mm) Black Acrylic settings

Same material on xTool F1 Ultra. Engrave stays the same regardless of thickness; cut changes with thickness.

Engrave (any thickness)

3mm · P40 S80 · this one3mm · P40 S?3mm · P80 S80 3mm · P40 S80 3mm · P15 S80 3mm · P55 S700 3mm · P55 S700 3mm · P35 S?3mm · P45 S1800 3mm · P70 S600 3mm · P50 S800

Cut by thickness

3mm · P80 S4 3mm · P100 S4

Score

3mm · P60 S1500 3mm · P70 S300

Community Feedback

No votes yet — be the first to report how these settings worked.

Export

xTool machine: open it straight in xTool Studio, or download a .mxs (Studio → Materials → Import).

Shop xTool lasers and UV printers

Every xTool machine in this library, with our discount code.

Code ERIK100: $100 off $1,699+ (or ERIK80: $80 off $999+)

Machine Context

BrandxTool

ModelF1 Ultra

Laser typeFiber/Infrared

Wattage20W

Compare against your own machine before treating these as a starting point.

Material Details

Material1/8"(3mm) Black Acrylic

Color / Finishblack

Size3mm

SupplierxTool

Buy this material →

Code ERIK100 — $100 off $1,699+ (or ERIK80 — $80 off $999+)

Shop machine — xTool →

Code ERIK100 — $100 off $1,699+ (or ERIK80 — $80 off $999+)

Provenance

Source type

Community report

Shared by a maker in the community. Helpful for context, but not verified for every setup.

Source

Shared by @Adam Kent in Atomm, xTool's community

View the original post →
