Pine Wood test grid

DiodeCommunity report

Pine Wood

Shared by @potatie78 on Atomm

Important safety notice

Settings are starting points — always run a test cut on scrap before your final piece. Follow your manufacturer's guidance, wear eye protection, and ensure proper ventilation.

Laser Settings

Engrave · Bitmap · Flat Surface

Power

80

Speed

130

LPC

128

Passes

1

Thickness

10mm

Engraved onto a Pine coaster using my M1 Ultra. I placed the coaster onto my plate and took a snapshot of it to upload into my canvas. I then removed the background of the image to ensure it only engraved the the letter and flowers and sized it to fit.

More Pine Wood settings

Same material on xTool M1 Ultra. Engrave stays the same regardless of thickness; cut changes with thickness.

Engrave (any thickness)

10mm · P80 S130 · this one10mm · P80 S140 15mm · P50 S140 15mm · P80 S125 15mm · P50 S140 10mm · P100 S140 10mm · P50 S150 10mm · P40 S250

Score

10mm · P60 S100 10mm · P50 S100

Community Feedback

No votes yet — be the first to report how these settings worked.

Export

xTool machine: open it straight in xTool Studio, or download a .mxs (Studio → Materials → Import).

All American Print Supply

DTF and UV printers, supplies and xTool machines.

Code FOUNDRY: 5% off, machines included

Machine Context

BrandxTool

ModelM1 Ultra

Laser typeDiode

Wattage10W

Compare against your own machine before treating these as a starting point.
